VICWA® Woven Fabric Data Sheet

Model	Fiber Type (Denier)	Density (Warp/Weft per CM)	Weight (GSM)	Thickness (MM)	Width (MM)	Tensile Strength – Warp (KN/2.5CM)	Tensile Strength – Weft (KN/2.5CM)	Length (M)
VF0206P	200D	13.5*13.5	60	0.08	500-2000	≥1.6	≥1.8	100
VF0408P	400D	12.0*12.0	80	0.11	500-2000	≥2.0	≥2.2	100
VF0412P	400D	13.5*13.5	122	0.14	500-2000	≥2.6	≥2.7	100
VF0610P	600D	8.0*8.0	100	0.15	500-2000	≥2.5	≥2.6	100
VF0816P	840D	8.5*8.5	160	0.25	500-2000	≥3.6	≥3.8	100
VF0820P	840D	10.5*10.5	200	0.30	500-2000	≥4.0	≥4.2	100
VF1014P	1000D	6.0*6.0	140	0.22	500-2000	≥3.5	≥3.6	100
VF1016P	1000D	7.0*7.0	160	0.24	500-2000	≥3.5	≥3.7	100
VF1020P	1000D	9.0*9.0	200	0.26	500-2000	≥3.8	≥4.0	100
VF1025P	1000D	11.5*11.5	255	0.31	500-2000	≥4.8	≥5.2	100
VF1027P	1000D	12.2*12.2	270	0.34	500-2000	≥5.0	≥5.3	100
VF1517P	1500D	5.0*5.0	170	0.23	500-2000	≥3.3	≥3.5	100
VF1520P	1500D	6.0*6.0	200	0.26	500-2000	≥3.8	≥4.2	100
VF1541P	1500D	12.7*12.7	410	0.62	500-2000	≥7.7	≥8.2	100
VF1546P	1500D	6.5*6.5	460	0.68	500-2000	≥8.2	≥8.5	100
VF3030P	3000D	4.5*4.5	300	0.53	500-2000	≥5.2	≥5.5	100
VF3041P	3000D	6.2*6.2	410	0.62	500-2000	≥7.5	≥8.0	100
VF3043P	3000D	6.5*6.5	430	0.65	500-2000	≥7.6	≥8.1	100
VF3046P	3000D	6.7*6.7	460	0.70	500-2000	≥8.2	≥8.5	100
VF3063T	3000D	9.2*9.2	635	1.05	500-2000	≥11.0	≥11.5	100
