MICEX®Short Fiber (Meta-Aramid)
MICEX®Short Fiber (Meta-Aramid) Data Sheet
| Test Item | Unit | MC1551 | MC2051 | MC2551 | MC3051 | MC4051 | MC5076 |
|---|---|---|---|---|---|---|---|
| Linear Density | Den | 1.5±0.2 | 2.0±0.2 | 2.5±0.2 | 3.0±0.2 | 4.0±0.5 | 5.0±0.5 |
| Fiber Length | mm | 51.0±2.0 | 51.0±2.0 | 51.0±2.0 | 51.0±2.0 | 51.0±2.0 | 76.0±3.0 |
| Breaking Force | g/d | 4.8±0.5 | 4.8±0.5 | 4.8±0.5 | 4.8±0.5 | 4.8±0.5 | 5.0±0.5 |
| Elongation at Break | % | 40.0±10.0 | 40.0±10.0 | 40.0±10.0 | 40.0±10.0 | 45.0±10.0 | 45.0±10.0 |
| Oil Content | % | 0.6±0.2 | 0.6±0.2 | 0.6±0.2 | 0.6±0.2 | 0.55±0.1 | 0.55±0.1 |
| Crimps Per Inch | ea/inch | 12±2.0 | 12±2.0 | 12±2.0 | 12±2.0 | 9.5±3.0 | 9.5±3.0 |
